Canon EOS R5C Mirrorless Cinema Camera

Imaging

Lens Mount	Canon RF
Lens Communication	Yes, with Autofocus Support
Sensor Resolution	Actual: 47.1 Megapixel Effective: 45 Megapixel (8192 x 5464)
Sensor Type	36 x 24 mm (Full-Frame) CMOS
Crop Factor	1.6x
Pixel Pitch	5.5 µm
Image Stabilization	Digital
Built-In ND Filter	None
Internal Filter Holder	No
Capture Type	Stills & Video

Exposure Control

Shutter Type	Electronic Shutter, Mechanical Focal Plane Shutter
Shutter Speed	Mechanical Shutter 1/8000 to 30 Seconds Electronic Front Curtain Shutter 1/8000 to 30 Seconds Electronic Shutter 1/8000 to 0.5 Seconds
Bulb/Time Mode	Bulb Mode
ISO Sensitivity	Photo 100 to 51,200 in Manual Mode (Extended: 50 to 102,400) 100 to 12,800 in Auto Mode (Extended: 100 to 51,200) Video 100 to 51,200 (Extended: 50 to 102,400)
Metering Method	Center-Weighted Average, Evaluative, Partial, Spot
Exposure Modes	Aperture Priority, Manual, Program, Shutter Priority
Exposure Compensation	-3 to +3 EV (1/3, 1/2 EV Steps)
Metering Range	-3 to 20 EV
White Balance	0 to 0K Presets: Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent (White), Tungsten
Continuous Shooting	Mechanical Shutter Up to 12 fps at 45 MP for up to 180 Frames (Raw) / 350 Frames (JPEG) Electronic Shutter Up to 20 fps at 45 MP for up to 83 Frames (Raw) / 170 Frames (JPEG)
Interval Recording	Yes
Self-Timer	2/10-Second Delay

Internal Video Capture

Raw Recording	Raw, Cinema RAW Light 8192 x 5464 at 23.98/24.00/25/29.97/50/59.94 fps [1030 to 2570 Mb/s] 5952 x 3140 at 23.98/24.00/29.97/50/59.94 fps [544 to 1360 Mb/s] 2976 x 1570 at 23.98/24.00/25/29.97/50/59.94 fps [138 to 344 Mb/s]
Recording Modes	Raw 12-Bit DCI 8K (8192 x 4320) at 23.98p/24.00p/25p/29.97p [2600 Mb/s] AVC-Intra/AVC-LongG/XF-AVC 4:2:2 10-Bit DCI 4K (4096 x 2160) at 23.98p/24.00p/25p/29.97p/59.94p/100p/119.88p [160 to 810 Mb/s] UHD 4K (3840 x 2160) at 23.98p/25p/29.97p/50p/59.94p/100p/119.88p [160 to 810 Mb/s] Full HD (1920 x 1080) at 23.98p/25p/29.97p/50p/59.94p [50 to 310 Mb/s] HD (1280 x 720) at 50p/59.94p [8 to 12 Mb/s] AVC-LongG/MP4 4:2:2 10-Bit DCI 8K (8192 x 4320) at 23.98p/24.00p/25p/29.97p [400 to 540 Mb/s] UHD 8K (7680 x 4320) at 23.98p/25p/29.97p [400 to 540 Mb/s] DCI 4K (4096 x 2160) at 23.98p/24.00p/25p/29.97p/50p/59.94p/100p/119.88p [100 to 225 Mb/s] UHD 4K (3840 x 2160) at 23.98p/25p/29.97p/50p/59.94p/119.88p [100 to 225 Mb/s] DCI 2K (2048 x 1080) at 23.98p/24.00p/25p/29.97p/50p/59.94p [35 to 50 Mb/s] Full HD (1920 x 1080) at 23.98p/25p/29.97p/50p/59.94p [35 to 50 Mb/s] HD (1280 x 720) at 50p/59.94p [8 to 12 Mb/s] AVC-LongG/MP4 4:2:0 8-Bit DCI 4K (4096 x 2160) at 23.98PsF/24.00p/25p/29.97p/50p/59.94p/119.88p [100 to 225 Mb/s] UHD 4K (3840 x 2160) at 23.98p/24.00p/25p/29.97p/50p/59.94p [100 to 225 Mb/s] DCI 2K (2048 x 1080) at 23.98p/24.00p/25p/29.97p/50p/59.94p [35 to 50 Mb/s] Full HD (1920 x 1080) at 23.98p/24.00p/29.97p/50p/59.94p [35 to 50 Mb/s] HD (1280 x 720) at 50p/59.94p [8 to 12 Mb/s]
Sensor Crop Modes	Super35 / APS-C 5952 x 3184 4096 x 2160 3840 x 2160 Super16 2976 x 1570
Sensor Crop While Recording	5K (5088 x 3392) in 1.6:1 When Recording in Raw 2K (2400 x 1600) in 1.6:1 When Recording in Raw
Gamma Curve	Canon Log 3, HDR-HLG, HDR-PQ, Rec2020, Rec709
Recording Limit	Unlimited
Video System	NTSC/PAL

External Video Capture

External Recording Modes	4:2:2 10-Bit via HDMI DCI 4K (4096 x 2160) up to 59.94p UHD 4K (3840 x 2160) up to 59.94p
IP Streaming	None

Still Image Capture

Image Sizes	3:2 JPEG / Raw 8192 x 5464 5088 x 3392 3:2 JPEG / Raw 8192 x 5464 5808 x 3872 4176 x 2784 2400 x 1600 4:3 JPEG / Raw 7280 x 5464 5152 x 3872 3715 x 2784 2112 x 1600 16:9 JPEG / Raw 8192 x 4608 5808 x 3264 4176 x 2344 2400 x 1344 1:1 JPEG / Raw 5456 x 5456 3872 x 3872 2784 x 2784 1600 x 1600
Aspect Ratio	1:1, 3:2, 4:3, 16:9
Image File Format	C-RAW, HEIF, JPEG, Raw
Bit Depth	14-Bit

Interface

Media/Memory Card Slot	Slot 1: CFexpress Type B Slot 2: SD/SDHC/SDXC (UHS-II)
Video I/O	1 x Micro-HDMI Output
Audio I/O	1 x 1/8" / 3.5 mm TRS Stereo Mic/Line Input 1 x 1/8" / 3.5 mm TRS Stereo Headphone Output
Power I/O	1 x USB Type-C (9 VDC at 3 A) Input
Other I/O	1 x USB Type-C (USB 3.2 / 3.1 Gen 2) (Shared with Power Input)
Wireless	Bluetooth Control 2.4 / 5 GHz Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), Wi-Fi (802.11b/g), Wi-Fi Video Output, Control
Global Positioning (GPS, GLONASS, etc.)	None

Monitor

Size	3.2"
Resolution	2,100,000 Dot
Display Type	Free-Angle Tilting Touchscreen LCD

Viewfinder

Type	Built-In Electronic (OLED)
Size	0.5"
Resolution	5,790,000 Dot
Eye Point	23 mm
Coverage	100%
Magnification	Approx. 0.76x
Diopter Adjustment	-4 to +2

Focus

Focus Type	Auto and Manual Focus
Focus Mode	Continuous-Servo AF, Manual Focus, Single-Servo AF
Autofocus Points	Phase Detection: 1053
Autofocus Sensitivity	-6 to +20 EV
Built-In Flash	No
Maximum Sync Speed	1/250 Second
Flash Compensation	-3 to +3 EV (1/3, 1/2 EV Steps)
Dedicated Flash System	eTTL
External Flash Connection	Hot Shoe

Environmental

Operating Temperature	32 to 104°F / 0 to 40°C
Operating Humidity	0 to 85%

General

Battery Type	Canon LP-E6N
Tripod Mounting Thread	1 x 1/4"-20 Female (Bottom)
Accessory Mount	1 x Intelligent Hot Shoe
Dimensions (W x H x D)	5.6 x 4 x 4.4" / 142.2 x 101.6 x 111.8 mm
Weight	1.5 lb / 680 g (Body Only) 1.7 lb / 770 g (With Battery, Recording Media)

Ready for Anything

For all the wedding videographers, drone camera operators, and multimedia journalists who have professional photo still and cinema video production needs, get ready for a new type of shooting experience with the EOS R5 C Mirrorless Cinema Camera from Canon. With a simple switch, the R5 C is a full featured still photo camera with all the settings of the R5 EOS mirrorless camera. When switched in the other direction, it becomes a full-frame 8K60 Cinema EOS camera that internally records 12-bit Cinema RAW Light footage. There's no more need to carry a second camera with you to your production when stills and video are available within a single compact design.



The R5 C enhances a number of features in comparison to its siblings the R5 and C70, including 4K120 recording, HDMI RAW output, Canon Log 3 HLG/PQ support, unlimited recording time, a timecode port, Dual Pixel CMOS AF with eye detection, an active cooling system, a high-power LP-E6NH battery, 13 reassignable buttons, and a multi-function shoe for XLR adapters. The camera also retains the reliable features of those cameras such as Wi-Fi/Bluetooth, footage compatibility with DaVinci Resolve and Canon apps, an electronic RF mount, CFexpress/SD card slots, a similar button layout, and more. The EOS R5 C is also moisture and dustproof to the same level as its cinema cousin, the EOS C70. And all this is packed into a tiny 1.7 lb body that is just asking to become your go-to drone camera.
